Description

• Single-phase, fan-cooled, compact MIG welder with advanced IGBT technology.
• Multi-function welder with MIG, MMA, lift TIG function.
• Adjustable burn back control.
• Self-compensate voltage fluctuation, less spatter easy arc.
• Weld flux cored and gas-less wire.
• Brand: Pinnacle
• Rated Input Voltage: AC 230V ±10%
• Rated Input Frequency: 50/60Hz
• Rated Input Power: 10.4kVA
• Rated Input Current: 45A
• Output Voltage Range: 16-25.6V
• Rated Duty Cycle: 60%
• Power Factor: 0.85
• Efficiency: 85%
• Electrode Size: 2.5 / 3.2 / 4.0 / 5.0mm
• Wire Size: 0.6 / 0.8 / 1.0mm
• Wire Feeder: Internal
• Torch Type: MB25
• Spool Size: 15KG Roll
• Insulation Class: F
• Protection Class: IP21
• Dimensions: 880 x 290 x 610mm
• Weight: 43kg
